| Technical details |
| Vendor | Synology |
| Sustainability certificates | RoHS |
| Performance |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Y |
| Backup features | iSCSI LUN |
| Noise level | 51.3 dB |
| Snapshot | Y |
| Web-based management | Y |
| Reset button | Y |
| Multilingual support | Y |
| On (off switch) | Y |
| Browser supported | Chrome, Firefox, Edge,Internet Explorer 10+, Safari 10+, Chrome |
| Design |
| Chassis type | Rack (2U) |
| LED indicators | Power, Status |
| Product colour | Black, Grey |
| Number of fans | 2 fan(s) |
| Cooling type | Active |
| Fan diameter | 60 mm |
| Storage |
| Number of storage drives supported | 12 |
| Storage interfaces | Serial ATA III,Serial Attached SCSI (SAS) |
| Supported storage drive types | HDD, SSD |
| RAID levels | 0 |
| Storage drives installed | N |
| Maximum supported storage capacity | 192 TB |
| Installed storage drive type | N |
| Hot-swap drive bays | Y |
| Supported file systems | BTRFS |
| RAID support | Y |
| Storage drive sizes supported | 2.5.3.5 " |
| Memory |
| Internal memory | 8 GB |
| Maximum RAM supported | 64 GB |
| Internal memory type | DDR4 |
| Memory slots | 4 |
| Memory form factor | UDIMM |
| Power |
| Redundant power supply (RPS) support | Y |
| Power supply unit (PSU) capacity | 500 W |
| Power consumption (HDD standby) | 274.38 W |
| Power consumption (typical) | 417.48 W |
| Number of power supply units | 1 |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power supply location | Built-in |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports | 3 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| USB port | N |
| Software |
| Linux operating systems supported | Y |
| Server operating systems supported | Windows Server 2008,Windows Server 2012,Windows Server 2013,Windows Server 2016 |
| Other operating systems supported | Solaris 10,Solaris 11,VMware ESX/ESXi 5.0,VMware ESX/ESXi 5.1,VMware ESX/ESXi 6.0,VMware ESX/ESXi 6.5 |
| Network |
| Ethernet LAN | Y |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| Wi-Fi | N |
| Link aggregation | Y |
| Ethernet LAN data rates | 1000.10000 Mbit/s |
| Supported network protocols | iSCSI, Telnet, SSH, SNMP |
| iSCSI support | Y |
| Processor |
| Processor cache | 6 MB |
| Processor manufacturer | Intel |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| PCI Express configurations | 1x16,1x4,1x8 |
| Processor frequency | 2.4 GHz |
| Thermal Design Power (TDP) | 45 W |
| Processor lithography | 14 nm |
| Processor codename | Broadwell |
| Processor series | Intel Xeon D-1500 |
| Processor family | Intel® Xeon® D |
| Maximum internal memory supported by processor | 128 GB |
| Processor package size | 37.5 x 37.5 mm |
| Conflict-Free processor | Y |
| Processor socket | BGA 1667 |
| Stepping | V2 |
| Processor model | D-1521 |
| Processor cores | 4 |
| Processor code | SR2DF |
| Processor threads | 8 |
| PCI Express slots version | 2.0,3.0 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.7 GHz |
| Packaging content |
| Cables included | AC |
| Quick installation guide | Y |
| Weight & dimensions |
| Height | 88 mm |
| Width | 482 mm |
| Depth | 724 mm |
| Weight | 19700 g |
| Other features |
| Processor ARK ID | 91202 |
| Processor special features |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Thermal Monitoring Technologies | Y |
| Intel Trusted Execution Technology | Y |
| Intel Enhanced Halt State | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Embedded options available | N |
| Intel TSX-NI | Y |
| Intel® Secure Key | Y |
| Intel 64 | Y |
| Intel® OS Guard | Y |
| UART | Y |
| Intel Virtualization Technology for Directed I (O (VT-d)) | Y |
| Maximum number of PCI Express lanes | 32 |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Y |
| Intel TSX-NI version | 1.00 |
| Memory types supported by processor | DDR3-SDRAM,DDR4-SDRAM |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Operational conditions |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Operating altitude | 0 - 5000 m |
| Operating relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -20 - 60 °C |
| Certificates |
| Certification | EAC VCCI CCC RCM KC FCC CE BSMI |
