| General |
| Processor model | Intel Core i5 (14. Gen.) 14500 / 24 MB Intel Smart Cache, max. Turbo-Frequency 5.0 GHz) |
| Operating system | Windows 11 Pro |
| Software |
| Pre-installed software | 1 month trial version for new Microsoft® 365 user |
| Processor |
| Processor family | Core i5 |
| Processor cores | 14-Core |
| Processor socket | FCLGA1700 Socket |
| Number of processors | 1 |
| Memory |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Maximum internal memory | 128 GB |
| Memory clock speed | 3200 MHz |
| Internal memory type | DDR4 |
| Memory slots | 4 pc(s) |
| Storage |
| Total storage capacity | 500 GB |
| HDD interface | 2x M.2 (Key M) 2280/2260/2242, PCIe 4.0 x4 mode, 4x SATA 6Gb/s ports
Supports SATA Raid, no NVMe Raid |
| RAID levels | RAID 0
RAID 1
RAID 5
RAID 10 |
| SSD interface | PCIe 4.0 |
| HDD capacity | 1 x 500 GB - SSD |
| Number of storage drives supported | 4x SATA 6Gb/s
2x M.2 (2280) PCIe/NVMe 4.0 x4 |
| Storage media | SSD M.2 |
| Performance |
| Series | Business |
| Noise level | 24,0 dB (Idle-Mode) |
| Audio output channels | 8-channel |
| Motherboard chipset | Intel B760 |
| Design |
| Chassis type | Mid tower |
| Certification | ISO 9001, Assembled in Germany
Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
| Keyboard form factor | Terra Cherry |
| Keyboard |
| Keyboard language | German |
| Connectivity technology | Wired |
| Device interface | USB |
| Technical details |
| Localization | German |
| Packaging content |
| Included Accessories | Quick Start Guide, Powercord EU |
| Expansion slots |
| Expansion slots | 1x PCIe 4.0/3.0 x16 slot
2x PCIe 3.0 x1 1x PCIe 4.0/3.0 x16 slot
2x PCIe 3.0 x1 |
| Weight & dimensions |
| Height | 43.5 cm |
| Width | 18 cm |
| Depth | 42 cm |
| Weight | 8 kg |
| Other features |
| Number of drive bays | 1 front - 13.3 cm ( 5.25" )
1 front - 8.9 cm ( 3.5" )
2 internal - 8.9 cm ( 3.5"/ 2.5" with adapter)
1 internal 6.4 cm (for 2.5" SSD) |
| Interface | 1x HDMI, 2x DP (Display Port), 1x VGA
5x USB 3.2 Gen1 ports Type-A (2x front), 2x USB 2.0 ports, 1x USB 3.2 Gen2 Type-C
1x LAN RJ-45, 3x Audio jacks, 1x PS/2
Option: 1x COM, 1x LPT, 1x TPM module |
| Compatible operating systems | Windows 10, Windows 11 |
| Motherboard manufacturer | Gigabyte B760M DS3H |
| Cooling type | TERRA Silent Heatpipe Cooler |
| Compliance industry standards | CE, ISO 9001, Assembled in Germany
Compatibility: PC2001, SMBios (DMI) 2.3, PCI 2.2,WFM 2.0, EnergyStar, EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
| Special features | TPM 2.0
Secure Boot
Windows Autopilot ready
2x USB 3.2 Gen1 Typ A + Audio in Front |
| Mouse |
| Mouse included | Terra wheel mouse optical |
| Graphics |
| On-board graphics adapter memory | Dynamisch GB |
| On-board graphics adapter maximum resolution | DisplayPort 1.2 max. 4096 x 2304@60Hz
HDMI 2.1 max. 4096 x 2160@60Hz
D-Sub (VGA) max. 1920 x 1200@60Hz |
| Graphics card | Intel UHD Graphics 770 |
| On-board graphics card model | Intel UHD Graphics 770 |
| Graphics adapter ports | 1x HDMI, 2x DP (Display Port), 1x VGA
Supports Quad-Monitoring |
| Power |
| Maximum input power | 400 Watt |
| Nominal power | Ø 20 Watt Idle-Mode
Ø 77 kWh a year (TEC = Typical Energy Consumption)
Further information regarding Energy consumption see www.wortmann.de/green and/ or Quicklinks for this product (if available) |
| AC adapter input voltage | AC 230V ( 50 Hz ) |
| Operational conditions |
| Operating temperature (T-T) | 0° - 35° C |
| Maximum operating temperature range (T-T) | 32 °C |
| Recommended humidity operating range | 10 - 75% (non-condensing) |
| Network |
| Ethernet LAN | RJ45 |
| LAN controller | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps, WOL/PXE |
| Data link protocols | Ethernet
Fast Ethernet
Gigabit Ethernet
2.5 Gb Ethernet |
| Optical drive |
| Optical drive type | DVD±RW |
| Input device |
| Movement detection technology | Optical |
| Device interface | USB |
