| General |
| Processor model | Intel Core i5 (10. Gen.) 10500 / 3.1 GHz (12 MB SmartCache, bis zu 4.5 GHz mit Intel Turbo Boost Technology) |
| Operating system | Windows 10 Pro |
| Software |
| Pre-installed software | 1 month trial version for new Microsoft® 365 user |
| Processor |
| Processor family | Core i5 |
| Processor cores | Quad-Core |
| Processor socket | FCLGA1200 Socket |
| Number of processors | 1 |
| Memory |
| Internal memory | 8 GB |
| Maximum internal memory | 128 GB |
| Memory clock speed | 3200 MHz |
| Internal memory type | DDR3 |
| Memory slots | 4x DDR4 PC2133 (1 slot already in use) |
| Storage |
| Total storage capacity | 500 GB |
| HDD interface | 6x SATA 6Gb/s ports 1x M.2 slot (PCIe 4.0 x4/ verfügbar nur bei Verwendung einer 11th Gen CPU) 1x M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) |
| RAID levels | Raid 0 Raid 1 |
| SSD interface | PCIe (NVMe) |
| HDD capacity | 120 GB |
| Number of storage drives supported | 6 x SATA-3 (6 Gb/s), 1 x M.2, 1 x SATA Express port |
| Storage media | SSD M.2 |
| Performance |
| Series | Business |
| Noise level | 24,0 dB (Idle-Mode) |
| Audio output channels | 8-channel |
| Motherboard chipset | Intel B560 |
| Design |
| Chassis type | Mini tower |
| Certification | ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
| Keyboard form factor | Terra Cherry |
| Keyboard |
| Keyboard language | German |
| Connectivity technology | Wired |
| Device interface | USB |
| Technical details |
| Localization | German |
| Packaging content |
| Included Accessories | Quick Start Guide, Powercord EU |
| Expansion slots |
| Expansion slots | Slot 1: PCI Express 3.0 x16 for VGA Slot 2: PCI Express 3.0 x1* Slot 3: PCI (3.3V/5V) Slot 4: PCI Express 3.0 x16 @ x4 oder x1 mode *In case of using a Dual-Slot PCI Express x16 VGA, Slot#2 is covered 1x PCIe 4.0 (11th Gen CPU) /3.0 (10th Gen CPU) x16 slot, 1x PCIe 3.0 x16 (@ x4), 1x PCIe 3.0 x1 slots |
| Weight & dimensions |
| Height | 37.5 cm |
| Width | 18 cm |
| Depth | 39 cm |
| Weight | 7 kg |
| Other features |
| Number of drive bays | 2 front - 13.3 cm ( 5.25" ) 1 front - 8.9 cm ( 3.5" ) 1 internal - 8.9 cm ( 3.5"/ 2.5" with adapter)1 internal 6.4 cm (for 2.5" SSD) |
| Interface | 2x USB 3.2 Gen2 (1x Type-A, 1x Type-C), 2x USB 3.2 Gen1 (front), 6x USB 2.0 (2x vorne) DP 1.4, 2x HDMI, 3x Audio jacks, 1x PS/2 Option: 1x COM, 1x LPT 2x USB 3.2 Gen2 (1x Type-A, 1x Type-C), 2x USB 3.2 Gen1 (front), 6x USB 2.0 (2x vorne) DP 1.4, 2x HDMI, 3x Audio jacks, 1x PS/2, 1x LAN RJ45 Option: 1x COM, 1x LPT |
| Compatible operating systems | Windows 10 |
| Motherboard manufacturer | Asus PRIME B560M-A |
| Cooling type | TERRA Silent CPU cooler (active) |
| Compliance industry standards | CE, ISO 9001, Assembled in Germany Compatibility: PC2001, SMBios (DMI) 2.3, PCI 2.2,WFM 2.0, EnergyStar, EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
| Special features | TPM 2.0 2x USB 3.2 Gen1 Typ A + Audio in Front |
| Mouse |
| Mouse included | Terra wheel mouse optical |
| Graphics |
| On-board graphics adapter maximum resolution | HDMI max. 4096x2160 @ 24Hz (10th Gen CPU)/ HDMI max. 4096x2160 @ 60Hz (11th Gen CPU) DP max. 4096x2304 @ 60 Hz |
| Graphics card | Intel UHD Graphics 630 (1150 MHz) |
| On-board graphics card model | Intel UHD Graphics 630 (1150 MHz) |
| Power |
| Power source | Power supply |
| Power consumption (standby) | Ø 0.9 Watt (S3 Mode, Suspend to RAM, WOL aktiviert) 0,30 Watt Soft off (S5 Mode) |
| Maximum input power | 350 Watt |
| AC adapter input voltage | AC 230V ( 50 Hz ) |
| Operational conditions |
| Operating temperature (T-T) | 0° - 35° C |
| Maximum operating temperature range (T-T) | 32 °C |
| Recommended humidity operating range | 10 - 75% (non-condensing) |
| Network |
| Ethernet LAN | Netzwerkadapter - integriert |
| LAN controller | Intel I219V, WOL/PXE |
| Optical drive |
| Optical drive type | DVD±RW |
| Input device |
| Movement detection technology | Optical |
| Device interface | USB |
