Descriere
Conexiune |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| HDMI ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Combo headphone/mic port | Yes |
| HDMI version | 2.0 |
| USB Power Delivery | Yes |
| USB Power Delivery up to | 100 W |
| USB Power Delivery revision | 3.0 |
| Connectivity technology | Wired |
| DisplayPorts quantity | 2 |
| Headphone connectivity | 3.5 mm |
| Headphone outputs | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| DisplayPort version | 1.4 |
| USB Type-C DisplayPort Alternate Mode | Yes |
Reţea |
| Ethernet LAN (RJ-45) ports | 1 |
| Networking standards | IEEE 802.3ab |
| Ethernet LAN | Yes |
| Wake-on-LAN ready | Yes |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
Performanță |
| Card reader integrated | No |
| Product colour | Grey,Silver |
| Housing material | Plastic |
| HD type | 4K Ultra HD |
| LED indicators | Power |
| Maximum digital resolution | 4096 x 2160 pixels |
| Cable lock slot | Yes |
| Data transfer rate | 10 Gbit/s |
| Cable lock slot type | Kensington |
| Maximum refresh rate | 60 Hz |
Managementul energiei |
| Output voltage | 24 V |
| Output current | 5.41 A |
| Input current | 2.5 A |
| Power plug type | Type M |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 15 W |
Software |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Mac operating systems supported | Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.15.3 Catalina,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Mac OS X 13.0 Ventura |
| Other operating systems supported | ChromeOS |
| Linux operating systems supported | Yes |
| Mobile operating systems supported | Android |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 70 °C |
| Operating relative humidity (H-H) | 0 - 85 % |
| Storage temperature (T-T) | -10 - 55 °C |
Greutate ÅŸi dimensiuni |
| Depth | 190 mm |
| Width | 85 mm |
| Height | 30 mm |
| Weight | 350 g |
Datele de ambalare |
| Package width | 205 mm |
| Package depth | 250 mm |
| Package height | 50 mm |
| Package weight | 1100 g |
Conţinutul de ambalaje |
| Cables included | AC,USB Type-C to USB Type-C |
| AC adapter included | Yes |
| Quick start guide | Yes |
Date logistice |
| Master (outer) case length | 430 mm |
| Master (outer) case width | 280 mm |
| Master (outer) case height | 290 mm |
| Products per master (outer) case | 10 pc(s) |
Alte caracteristici |
| Chipset | DisplayLink - DL-6950-N, VIA - VL817C0, Parade - PS176C0 |
