| Technical details |
| Vendor | APC by Schneider Electric |
| Sustainability certificates | RoHS |
| Ports & interfaces |
| Serial interface type | RJ-45 |
| Serial interface | Y |
| USB port | Y |
| SmartSlot | Y |
| Power plug | C20 coupler |
| AC outlet types | C13 coupler, C19 coupler |
| Weight & dimensions |
| Height | 85 mm |
| Width | 432 mm |
| Depth | 635 mm |
| Package depth | 871 mm |
| Package height | 246 mm |
| Package width | 599 mm |
| Package weight | 39290 g |
| Weight | 31300 g |
| Battery |
| Battery recharge time | 3 h |
| Typical backup time at half load | 11.8 min |
| Typical backup time at full load | 4 min |
| Battery life (max) | 5 year(s) |
| Hot-swap battery | Y |
| Battery technology | Sealed Lead Acid (VRLA) |
| Cold start | Y |
| Automatic battery test | Y |
| Battery capacity | 505 VAh |
| Other features |
| Output voltage | 230 V |
| Design |
| Cable length | 2.44 m |
| LED indicators | Battery replacement |
| Product colour | Black |
| Certification | CE, VDE, RCM, EAC, IEC/EN 62040-1, IEC/EN 62040-2, UL-1778, FCC 15 A, CSA |
| Rack capacity | 2U |
| Form factor | Rackmount |
| International Protection (IP) code | IP20 |
| Display type | LCD |
| Features |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Y |
| Auto-restart | Y |
| Audible alarm(s) | Y |
| UPS topology | Double-conversion (Online) |
| Emergency Power Off (EPO) | Y |
| Output power capacity | 3 kVA |
| Surge energy rating | 340 J |
| Noise level | 55 dB |
| Audible alarm modes | Battery replacement |
| Input frequency | 40 - 70 Hz |
| Efficiency | 92 % |
| Output power | 2700 W |
| Power protection features | Overload |
| Output voltage Total Harmonic Distortion (THD) | 2 % |
| Surge protection | Y |
| Crest factor | 3:1 |
| Input operation voltage (max) | 275 V |
| Input operation voltage (min) | 100 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Logistics data |
| Products per pallet | 6 pc(s) |
| Operational conditions |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Non-operating altitude | 0 - 15000 m |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -15 - 45 °C |
| Packaging data |
| Quick installation guide | Y |
