Technical details |
| |
| |
Features |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Password protection | Yes |
Design |
| Product colour | White |
| Cable lock slot type | Kensington |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Product type | Standard throw projector |
Power |
| Power source | AC |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100-240 V |
| Power consumption (typical) | 327 W |
| Power consumption (economy mode) | 225 W |
Operational conditions |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -10 - 60 °C |
Weight & dimensions |
| Width | 309 mm |
| Depth | 282 mm |
| Package depth | 390 mm |
| Package weight | 4.59 kg |
| Height | 90 mm |
| Package width | 385 mm |
| Weight | 3.1 kg |
| Package height | 170 mm |
Network |
| |
| |
Packaging content |
| Batteries included | Yes |
| Manual | Yes |
| Cables included | |
| Remote control included | Yes |
| Warranty card | Yes |
| WLAN adapter included | Yes |
Software |
| |
| |
Multimedia |
| RMS rated power | 16 W |
| Built-in speaker(s) | Yes |
Ports & interfaces |
| HDMI ports quantity | 2 |
| Audio (L/R) in | 1 |
| Serial interface type | RS-232C |
| USB 2.0 ports quantity | 1 |
| VGA (D-Sub) ports quantity | 2 |
| DVI port | No |
| Microphone in | Yes |
| HDMI connector type | Full-size |
| USB 2.0 Type-B ports quantity | 1 |
Other features |
| |
| |
Logistics data |
| Products per pallet | 72 pc(s) |
| Harmonized System (HS) code | 85286200 |
| Quantity per pack | 1 pc(s) |
| Products per pallet (UK) | 72 pc(s) |
Video |
| Video processing | 10 bit |
| Full HD | Yes |
| 3D | No |
| Video colour modes | |
Lens system |
| Zoom ratio | 1.6:1 |
| Zoom capability | Yes |
| Throw ratio | 1.32 - 2.14:1 |
| Zoom type | Manual |
| Focal length range | 18.2 - 29.2 mm |
| Focus | Manual |
| Aperture range (F-F) | 1.51 - 1.99 |
Projector |
| Projector brightness | 4000 ANSI lumens |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 2400 ANSI lumens |
| Projection technology | 3LCD |
| Projection distance | 1.76 - 2.86 m |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Matrix size | 1.55 cm (0.61") |
| Keystone correction, vertical | -30 - 30° |
| Native aspect ratio | 16:9 |
| Vertical scan range | 100 - 120 Hz |
| Keystone correction, horizontal | -30 - 30° |
| Projector native resolution | 1080p (1920x1080) |
| Contrast ratio (typical) | 16000:1 |
| White light output | 4000 ANSI lumens |
| Colour light output | 4000 ANSI lumens |
Light source |
| Lamp type | UHE |
| Service life of light source (economic mode) | 17000 h |
| Service life of light source | 6500 h |
| Light source type | Lamp |
| Lamp power | 230 W |
